TP-Link VIGI NVR4032H 32 Channel Network Video Recorder

The VIGI professional surveillance system by TP-Link is dedicated to protecting the business that you've worked hard to build - whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.

• 32-Channel Live View and 4K HDMI Video Output
• Up to 16-ch @ 2MP (25fps) / 8-ch @ 4MP (25fps) Decoding Capability
• 16-Channel Synchronous Playback†
• 320 Mbps Incoming Bandwidth and 320 Mbps Outgoing Bandwidth
• 4× SATA Interfaces and 1 Up to 16 TB*
• H.265+ Compression Technology
• HDMI and VGA Simultaneous Output
• Remote Monitoring

Video and Audio:

• IP Video Input: 32-Channel
• Incoming Bandwidth: 320 Mbps
• Outgoing Bandwidth: 320 Mbps
• HDMI Output Resolution: 1 Channel, Resolution: 3840x2160/30Hz,1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
• VGA Output Resolution: 1 Channel, Resolution: 1920x1080/60Hz,1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz
• Video Output Mode: HDMI/VGA Independent Output
• Multi-View Display: 1/4/6/8/9/16/25/32/36

Decoding:

• Audio Compression: G.711A/G.711U/G.726
• Video Compression: H.265+/H.265/ H.264+/H.264
• Record Resolution: 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
• Synchronous Playback: 16-Channel†
• Capability: 4-ch@8MP (25fps), 6-ch@5MP (25fps), 8-ch@4MP (25fps), 10-ch@3MP (25fps), 16-ch@1080P (25fps)

Record Management:

• Record Mode: Manual Recording, Scheduling Recording, Motion Detection Recording
• Playback Mode: Instant Playback, Regular Playback, Tag Playback, Event Playback
• Backup Mode: Regular Backup, Video Clip Backup
• Playback Function: Play, Pause, Stop, Fast Forward, Fast Backward, Play By Frame. Full Screen, Video Clip, Export Clip, Digital Zoom, Lock Recording, Audio On/Off

Network:

• Protocol: UPnP (Plug and Play), NTP (Network Timing), TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP
• Mobile Phone Access: Android, iOS
• Web Browser: Chrome (57+), Firefox (52+), Edge (91+)
• Interoperability: ONVIF Profile S, CGI

External Interface:

• Network Interface: 2, RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface
• USB Interface: 2 Front USB 2.0 Ports, 1 Rear USB 3.0 Port
• Audio Interface: 1-ch RCA Input; 1-ch RCA Output
• Alarm In/Out: 16/4
• Serial Interface: 1, RS232
• Power: 1× AC Jack
• Reset Button: 1
• Speaker: N/A
• eSATA: N/A
• HDMI: 1
• VGA: 1

Hard Disk:

• SATA: 4 SATA Interfaces
• Capacity: Up to 16 TB Capacity for Each HDD

Alarm:

• General Alarm: Motion Detection, Video Tampering, Line-Crossing Detection, Intrusion Detection, Region Entering Detection, Region Exiting Detection, Object Abandoned/Removal Detection, Vehicle Detection, Human Detection. Note: The alarm function requires the use of a camera.
• Anomaly Alarm: Video Loss, Offline and IP Conflict, Disk Exception, Login Exception, Fan Exception. Note: The alarm function requires the use of a camera.
• Alarm Linkage: Recording, White Light Alarm, Buzzer, Log, Audible Alarm. Note: The alarm function requires the use of a camera.

General:

• Storage Temperature: -40–70 °C
• Storage Humidity: 10%~90% RH Non-Condensing
• Working Temperature: NVR: -10–55 °C; Power Adapter: 0–40 °C
• Working Humidity: 10%~90% RH Non-Condensing
• Dimensions (W X D X H): 440 × 330 × 44 mm
• External Power Supply: 100-240 VAC, 50 to 60HZ, 1.5A
• Net Weight: 4.0 Kg
• Gross Weight: 5.2 Kg
• Power Supply: 100-240 VAC, 50 to 60HZ, 1.5A
• Max. Power Consumption: 5 W (Without Disk), 48 W (With Disk)

• VIGI Network Video Recorder
• Mouse
• Installation Guide
• Power Cord
• HDD Power Cables
• HDD Data Cables
• Terminal Blocks
• Mounting Brackets
• Screws
• Rubber Feet
