Key Details:
- Model: EAP211-BRIDGE KIT
- Part #: AW001757
- Warranty: 3 Years
- Brand: TP Link
Ask Our Experts:
TP-Link EAP211 Omada 5GHz 867Mbps Indoor/Outdoor Wireless Bridge Kit
Long-distance PtMP & PtP wi-fi transmission, perfect for multiple scenarios.
- 802.11ac for up to 867 Mbps on the 5 GHz wireless data rate.
- Ideal for long-range wireless transmission up to 1 km.
- Auto-pairing and agile LEDs for efficient deployment.
- 3× Gigabit Ethernet ports for more high-speed IP camera connections.
- Supports Omada SDN for remote and centralised management.
- IP65 weatherproof enclosure and 6kV lightning protection ensure all-weather suitability.
- Supports Passive PoE for flexible deployment (adapter included).
Hardware Features:
- Interface: 3x Gigabit Ethernet Ports*6
- Button: Reset
- Power Supply: 12V DC / 24V Passive PoE (Passive PoE adapter included.)
- Max. Power Consumption: 11.5W
- Dimensions (W x D x H): 79 × 60 × 224 mm
- Antenna: Internal 2×2 Dual-polarized directional MIMO antennas; 5 GHz: 7.0 dBi; Horizontal: 70°, Vertical: 70°
- Weatherproof Enclosure: IP65
- Mounting: Pole Mounting (Accessories included)
Wireless Features:
- Coverage: 1000m(3280ft)5
- Wireless Standards: IEEE 802.11 a/b/g/n/ac
- Frequency: 5 GHz
- Signal Rate: 5 GHz: Up to 867 Mbps
- Wireless Functions: Mesh, MU-MIMO: 5G 2x2 MU-MIMO DL, Load Balance, Seamless Roaming (802.11r), Beamforming, Airtime Fairness, Multiple SSIDs: 8, Wireless Statistics, Wireless Schedule, Reboot Schedule, RADIUS Accounting, MAC Authentication, Static IP/Dynamic IP
- Wireless Security: VLAN, Access Control, Rogue AP Detection, Captive Portal Authentication, Maximum number of MAC Filter: 4,000, WPA-Personal/Enterprise, WPA2-Personal/Enterprise
- Transmission Power - CE: < 23dBm (5 GHz, band 1/2, EIRP); < 28.5dBm (5 GHz, band3, EIRP)
- Transmission Power - FCC: < 22dBm (5 GHz, band1/4)
Management Features:
- Omada App: Yes
- Restore & Backup: Yes
- Firmware update via Web: Yes
- NTP: Yes
- Centralized Management: Omada Hardware Controller (OC300), Omada Hardware Controller (OC200), Omada Software Controller, Omada Cloud-Based Controller
- Cloud Access: Yes. Require the use of OC300, OC200, the Omada Software Controller, or Omada Cloud-Based Controller.
- LED ON/OFF Control: Yes
- Management MAC Access Control: Yes
- SNMP: v1, v2c, v3
- SSH: Yes
- Web-based Management: Yes
Others:
- Certification: CE, FCC, RoHS
- Operating Temperature: -40 °C–70 °C (-40 °F–158 °F)
- Storage Temperature: -40 °C–70 °C (-40 °F–158 °F)
- Operating Humidity: 10%–90% non-condensing
- Storage Humidity: 5%–90% non-condensing
- EAP211-Bridge KIT
- Passive PoE Adapter
- Power Cord
- Installation Guide
- Mounting Kit
