Synology RackStation RS3617RPxs 12 Bay 8GB RAM 2RU Rack Mountable NAS with 12x 4TB Western Digital Enterprise Drives + Installation!

Highly scalable NAS designed for virtualization, data-intensive applications and service continuity for large scale businesses

Powerful storage solution

• RS3617RPxs provides rock-solid storage solution with great performance with over 491,000 sequential read IOPS and 3,900 MB/s sequential read throughput. DDR4 ECC UDIMM guarantees data accuracy and performance for mission-critical environments.

Ready for 10GbE and beyond

• PCIe 3.0 slots allow for faster networking options as you expand your infrastructure. Together with the built-in quad Gigabit ports, RS3617RPxs offers comprehensive connectivity options for link aggregation and failover configurations.

Complete iSCSI and virtualization solutions

• Synology iSCSI storage supports most virtualization solutions including VMware vSphere, Microsoft Hyper-V, Citrix Xen Server, and OpenStack Cinder, to enhance work efficiency. Create and manage virtual machines running multiple operating systems such as Windows, Linux, and DSM using Virtual Machine Manager.

CPU

• CPU Model: Intel Xeon D-1521 64-bit
• CPU Frequency: Quad Core 2.4 (base) / 2.7 (turbo) GHz
• Hardware Encryption Engine (AES-NI): Yes

Memory

• System Memory: 8 GB DDR4 ECC UDIMM
• Memory Module Pre-installed: 8GB (1 x 8GB)
• Total Memory Slots: 4
• Memory Expandable up to: 64 GB (16 GB x 4)

Storage

• Drive Bays: 12 Bays
• Compatible Drive Type: 3.5" SATA HDD, 2.5" SATA HDD, 2.5" SATA SSD
• Maximum Internal Raw Capacity: 144 TB (12 TB drive x 12) (Capacity may vary by RAID types)
• Installed: 12x 4TB Western Digital Enterprise Drives

Ports

• RJ-45 1GbE LAN Port: 4 (with Link Aggregation / Failover support)
• USB 3.0 Port: 2
• Expansion Port: 2

File System

• Internal Drives: Btrfs, EXT4
• External Drives: Btrfs, EXT4, EXT3, FAT, NTFS, HFS+, exFAT (exFAT Access is purchased separately in Package Center)

Other Features

• System Fan: 80 mm x 80 mm x 4 pcs
• Fan Speed Mode: Full-Speed Mode, Cool Mode, Quiet Mode
• Easy Replacement System Fan: Yes
• Power Recovery: Yes
• Noise Level: 50.2 dB(A)
• Scheduled Power On/Off: Yes
• Wake on LAN/WAN: Yes
• Power Supply Unit / Adapter: 2 X 500W
• AC Input Power Voltage: 100V to 240V AC
• Power Frequency: 50/60 Hz, Single Phase
• Power Consumption: 116.42 W (Access), 65.49 W (HDD Hibernation)

General Specifications

• Operating Temperature: 5°C to 35°C
• Storage Temperature: -20°C to 60°C
• Relative Humidity: 5% to 95% RH
• Dimensions (H x W x D): 88 x 430.5 x 692 mm
• Weight: 14.5 kg

• Main Unit with 12x 4TB WD Enterprise Drives pre-installed
