StarTech USB-C Triple Monitor Multiport Adapter with Power Delivery - 2x HDMI, 2x DisplayPort, 1x USB-C, 3x USB-A, 1x RJ45

This USB Type-C Multiport Adapter utilizes DP 1.4 Alt Mode and MST from a host computer to support up to three DisplayPort and/or HDMI displays. The USB-C dock provides 2x HDMI, 2x DisplayPort, a 3-port USB 3.2 Gen 2 Type-A (10Gbps) Hub, and a GbE, all through one connection to a laptop's USB-C or Thunderbolt 3/4 port. It offers advanced charging through a dedicated USB-C Power Delivery (PD) 3.0 pass-through port via an integrated 2 ft. (60 cm) USB-C host cable. The USB-C Multiport Adapter features driverless installation for hassle-free setup.

High-Performance Triple Video via MST:
The USB-C Multiport Adapter enhances video connectivity with support for up to three external monitors with resolutions up to 1x 4K (3840 x 2160p) at 60Hz and 2x 4K (3840 x 2160p) at 30Hz (Intel 11th Gen or later with DSC required for maximum performance). The Multiport Adapter features two HDMI 2.0b ports and two DisplayPort 1.4 ports, providing the ability to choose a combination of video outputs types. The Multiport Adapter utilizes the integrated or discrete GPU capabilities of the connected laptop to enable high performance graphics with minimal CPU usage.

Connect USB Peripherals:
The USB-C to USB 3.2 Gen 2 (10Gbps) hub features three USB-A ports for connecting USB HID devices and/or peripherals (e.g., storage devices).

Extra Long Cable & Durable Build:
The mini docking station features a built-in 2 ft. (60 cm) USB-C host cable with a high-quality TPE jacket and strain relief, for enhanced durability and longevity. The Multiport Adapter housing features a built-in EMI shield to protect the main board and integrated chips from electromagnetic interference, preventing signal interference between electronic devices and ensuring reliable performance.

100W Power Delivery:
Connect a USB-C power adapter to the pass-through port in order to charge the host laptop.

Reliable Network Connectivity:
The Gigabit Ethernet port ensures reliable wired network access. Support for Wake on Lan (WoL) allows you to boot the host computer from a remote location.

Connector(s):

• External Ports: 3 - USB 3.2 Type-A (9 pin, Gen 2, 10Gbps), 1 - RJ-45, 2 - DisplayPort (20 pin), 2 - HDMI (19 pin), 1 - USB Type-C (24 pin) USB Power Delivery Only
• Host Connectors: 1 - USB 3.2 Type-C (24 pin, Gen 2, 10Gbps)

Environmental:

• Operating Temperature: 0°C to 70°C (32°F to 158°F)
• Storage Temperature: -10°C to 70°C (14°F to 158°F)
• Humidity: 5~90% RH (Non-condensing)

Hardware:

• 4K Support: Yes
• Fast-Charge Port(s): No
• Displays Supported: 3
• Interface: USB 3.2 Gen 2 (10 Gbps)
• Bus Type: USB-C
• Industry Standards: HDMI 2.0b, DisplayPort 1.4, USB 3.2 Gen 2 (10 Gbps), USB Power Delivery Specification Rev. 3.0, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
• Chipset ID: Parade - PS8469, Synaptics - VMM5322, VIA - VL822, VIA - VL103, Realtek - RTL8153

Indicators:

• LED Indicators: 2 - Connection state/activity LEDs under GbE port

Performance:

• Wake On Lan: Yes
• Maximum Data Transfer Rate: USB 3.2 Gen 2 (10 Gbps)
• Maximum Digital Resolutions: Triple Display - 3840 x 2160 60Hz, 3840 x 2160 60Hz, 3840 x 2160 30Hz; Dual Display - 3840 x 2160 60Hz, 3840 x 2160 60Hz
• Type and Rate: USB 3.2 Gen 2 - 10 Gbit/s
• UASP Support: Yes
• Compatible Networks: 10/100/1000 Mbps
• PXE: Yes
• Full Duplex Support: Yes

Physical Characteristics:

• Color: Gray
• Product Length: 12.2 cm
• Product Width: 5.6 cm
• Product Height: 1.8 cm
• Weight of Product: 113.0 g
• Material: Plastic
• Cable Length: 60 cm

Power:

• Power Source: Bus Powered and Host USB-C Power Adapter
• Power Consumption (In Watts): 15W

OS Compatibility: Windows 10, 11, 11 ARM, Windows 8.1, Chrome OS 78.x

• 1 - USB-C Multiport Adapter
• 1 - Quick-Start Guide
