Key Details:
- Model: PEX4S953
- Part #: T053777
- Warranty: Lifetime
- Brand: StarTech
Ask Our Experts:

                                                        Special Offer
-
              Receive an additional 7% discount on any Startech quote when requesting a minimum of 5 units for Government & Public Sector Agencies/Organisations. Please state your organisation details when requesting a quote from our team. T&C apply.
StarTech PEX4S953 4-Port PCI Express RS232 Serial DB9 Adapter Card
This PCI Express RS232 serial adapter card lets you add four RS232 (DB9) serial ports to your computer through a PCI Express (PCIe) slot as if they were native serial ports. The 4-port PCIe serial card enables you to interact with serial devices, such as card readers, printers, PIN pads, and modems, at speeds of up to 921.6Kbps.
Connector:
- Connector Type: 1 - PCI Express x1
- Internal Ports: 1 - LP4 (4 pin; Large Drive Power)
- External Ports: 4 - DB-9 (9 pin, D-Sub)
Environmental:
- Operating Temperature: -10°C to 80°C (14°F to 176°F)
- Storage Temperature: -20°C to 100°C (-4°F to 212°F)
- Humidity: 5~85% RH
Hardware:
- Ports: 4
- Interface: Serial
- Bus Type: PCI Express
- Card Type: Low Profile (SP bracket incl.)
- Port Style: Integrated on Card
- Chipset ID: Asix AX99100
Performance:
- Serial Protocol: RS-232
- Max Baud Rate: 921.6 Kbps
- Data Bits: 5, 6, 7, 8, 9
- FIFO: 256 Bytes
- Flow Control: None, Xon/Xoff, RTS/CTS
- Parity: None, Odd, Even, Space, Mark
- Stop Bits: 1, 1.5, 2
- MTBF: 214,358 hours
Physical Characteristics:
- Color: Green
- Material: Steel
- Dimension (HxLxW): 1.5 cm x 7.5 cm x 6.3 cm
- Weight: 50.0 g
- Cable Length: 30 cm
Power:
- Input Voltage: 12V DC
OS Compatibility:
- Windows 7, 8, 8.1, 10, 11
- Windows Server 2003, 2008 R2, 2012, 2012 R2, 2016, 2019, 2022
- Linux 2.4.x and up - LTS Versions only
- 1 - 4 Port PCI Express Serial Card
- 1 - Full Profile Bracket (Installed)
- 1 - Low Profile Bracket
- 1 - 12 in [30 cm] DB44 to DB9 Break-out Cable
- 1 - Quick Start Guide
