Key Details:
- Model: SST-AT650R-BF
- Part #: DV018196
- Warranty: 3 Years
- Brand: Silverstone
Ask Our Experts:
Silverstone AT650R-BF 650W 80 Plus Bronze ATX 3.1 Power Supply
Compliant with ATX 3.1 standards and supports up to 2X power excursion
- Compliant with ATX 3.1 standards and supports up to 2X power excursion
- High efficiency with 80 PLUS Bronze certification
- 24/7 continuous power output with 50℃ operating temperature
- Silent running 120mm fan with 18 dBA minimum
- Multiple protection circuitry
- Flat cable design
- Active PFC+Double forward+DC to DC Design
- Color: Black (lead-free paint)
- Max. DC Output: 650W
- Combined +3.3V & +5V: 100W
- Combined +12V: 649.2W
- Input Voltage: 90 ~ 264 Vrms
- Input Frequency Range: 47Hz ~ 63Hz
- PFC: Active PFC (PF>0.9 at full load)
- Efficiency: 82% ~ 85% (at 20% ~ 100% loading)
- MTBF: 100,000 hours
- Operating temperature: 0°C ~ 50°C
- Protection: Over Power Protection, Over Voltage Protection, Short Circuit Protection, Under Voltage Protection
- Connectors: 1x 24 / 20-Pin motherboard connector, 2x 4-Pin + 4-Pin ATX 12V connectors, 4x 8 / 6-Pin PCIe connectors, 6x SATA connectors, 3x 4-Pin Peripheral connector
- Cooling System: Silent 120mm fan
- Noise Level: 18 dBA minimum
- Certification: 80 PLUS Bronze
- Form factor: ATX (PS2)
- Dimension (WxHxD): 150 × 86 × 140mm
- Weight: 1.52 kg
- Other: GPU Support list
