LG 86UL3J-N 86 Inch 3840 x 2160 (4K UHD) 8ms 330nit 16/7 ADS Digital Signage Display

LG One:Quick Share is a wireless screen sharing solution available through the UL3J series, USB transmission unit, and its app. You can simply share personal PC screen to the display with its USB dongle button and embedded Wi-Fi, and can adjust the basic setting values (volume, picture mode, auto bright, etc.) of the connected display without a remote control. Also, the Office Meeting Mode helps you to display the agenda, note before the meeting starts.

Remote Monitoring and Control:
This web-based monitoring solution is user-friendly and allows the user to be at ease. It enables the user to have full access anywhere at any time from their mobile phone & PC under network-accessible environment while having access to both current and past data. It allows the user to monitor the unit, make adjustments and control the unit remotely in real time

Compatible with AV Control Systems:
The UL3J series supports Crestron Connected for high compatibility with professional AV controls to achieve seamless integration and automated control, boosting business management efficiency.

Compatible with Video Conference System:
For effective visual meeting, the UL3J series supports its compatibility with Cisco solutions that offers powerful and integrated control for a smarter video conference.

Wireless Access Point:
UL3J series operates as a virtual router which can be a wireless access point for mobile devices.

Superb Picture Quality with Ultra HD Resolution:
With the resolution of UHD, it makes the color and details of the contents vivid and realistic. In addition, the wide viewing angle provides clear contents.

Sophisticated Slim Design:
This series is thin in bezel size and thickness, which saves space and enables easy installation. In addition, it increases the immersive experience from the screen and provides a sophisticated design, improving the décor of the space where the product is installed.

High Performance with LG webOS 6.0:
LG webOS 6.0, upgraded in SoC and web engine, is available on UL3J series for a smooth execution of several tasks. LG webOS smart signage platform enhances user convenience with intuitive GUI.

Built-in Speaker:
Contents will be enriched with sound effects from built-in speakers, without the need for purchasing or installing external speakers.

Panel:

• Screen Size: 86”
• Panel Technology: ADS
• Native Resolution: 3840 x 2160 (4K UHD)
• Brightness (Typ., nit): 330
• Contrast Ratio: 1,400:1
• Dynamic CR: 1,000,000 : 1
• Color gamut: DCI 80 %
• Viewing Angle (H x V): 178 × 178
• Color Depth: Advanced 8bit+FRC, 1.07 Billion colors
• Response Time: 8ms (G to G)
• Surface Treatment: 1%
• Operation Hours (Hours / Days): 16 / 7
• Portrait / Landscape: Yes / Yes

Mechanical Specification:

• Bezel Color: Ashed Blue
• Bezel Width: Off : 6.9/6.9/6.9/18.4 ; On : 15.9/15.9/15.9/19.9
• Weight (Head): 45.2 kg
• Monitor Dimensions (W × H × D): 1,927 x 1,104 x 59.9 mm
• Handle: No
• VESA Standard Mount Interface: 600 × 400 mm

Environment Conditions:

• Operation Temperature: 0 °C to 40 °C (Portrait Scene : 0 °C to 30 °C)
• Operation Humidity: 10 % to 80 %

Power:

• Power Supply: AC 100-240V~, 50/60Hz
• Power Type: Built-In Power

Power Consumption:

• Typ./Max.: TBD W / TBD W
• BTU (British Thermal Unit): 751 BTU/Hr(Typ.), 1024 BTU/Hr(Max.)

Connectivity:

• Input: HDMI (3, HDCP 2.2 / 1.4), USB 2.0 Type A (2)
• Output: Audio
• External Control: RS232C In / Out (4 Pin Phone Jack), RJ45 (LAN) In

Sound:

• Speaker: Yes
