LG 65TR3DK-B 65 Inch 3840 x 2160 (4K UHD) 390nit 8ms 16/7 IPS Interactive Display

LG CreateBoard offers a variety of educational templates and teaching tools such as a ruler, table, and sticky notes, allowing for active engagement by students and enabling intuitive classes. Editing images and videos becomes easy with LG CreateBoard, and created resources can be easily shared with others through QR codes.

Multi-touch:
LG CreateBoard can simultaneously detect up to 40 points for multi-touch functionality. This creates a lifelike board touch experience, helping students easily become accustomed and truly engage in classes. This leads to the maximum concentration and organic engagement of students.

Easy to Save / Import / Export:
LG CreateBoard includes simple import and export functionality. Resources can be saved and imported directly to and from Google Drive or OneDrive, and files can be imported from a USB drive (Users can browse resources saved on USB storage).

Wireless ScreenShare:
LG CreateBoard Share enables users to show up to 9 shared screens or a file on a screen in real-time when the LG CreateBoard Share app is installed on the device. Also, files from the host can be easily sent to any devices connected to the LG CreateBoard Share app, and several quick controls by the host are available.

LG ConnectedCare DMS:
LG ConnectedCare DMS is a cloud solution for remotely monitoring, controlling, and managing the status of LG CreateBoard installed in educational environments. This feature enables IT managers to operate and manage important resources on operating devices without physically visiting sites.

Broadcasting / Alert Messaging:
Messages and a range of other content can be sent from the main system to individual classroom devices connected to LG ConnectedCare DMS. In case of urgent occasions such as a fire or a natural disaster, alert messages can be distributed manually across the system, which help teachers and students promptly take safety action.

Bluetooth Connectivity:
LG CreateBoard supports wireless Bluetooth connections to various devices such as a speaker, mouse, keyboard, etc. This is optimal for building a hybrid environment so that online and offline classes can proceed smoothly.

Panel:
• Screen Size: 65 Inch
• Panel Technology: IPS
• Back Light Type: Direct
• Aspect Ratio: 16:9
• Native Resolution: 3840 x 2160 (UHD)
• Refresh Rate: 60Hz
• Brightness: 390nit (Typ., without Glass)
• Contrast Ratio: 1,200:1
• Dynamic CR: 5,000:1
• Color Gamut: NTSC 72%
• Viewing Angle (H x V): 178º x 178º
• Color Depth (Number of Colors): 16.7 Million colors
• Response Time: 8ms (G to G)
• Surface Treatment (Haze): Haze 25%
• Life time: 50,000Hrs (L30)
• Operation Hours (Hours/Day): 16/7

Connectivity:
• HDMI In: YES (3ea)
• HDMI In (HDCP Ver.): 2.2
• DP In: NO
• DVI-D In: NO
• RGB In: YES
• Audio In: YES
• RS232C In: YES
• RJ45(LAN) In: YES (1ea)
• IR In: NO
• USB In: USB3.0 Type A (4ea), USB2.0 Type A (1ea), USB Type C (1ea)
• HDMI Out: YES
• DP Out: NO
• Audio Out: YES
• Touch USB: USB2.0 Type B (2ea)
• External Speaker Out: NO
• RS232C Out: NO
• RJ45(LAN) Out: YES

Mechanical Specification:
• Bezel Color: Black
• Bezel Width: T/R/L/B : 15/15/15/44mm
• Weight (Head): 35.0Kg
• Monitor Dimensions (W x H x D): 1488.4 × 896.6 × 87.2mm
• Carton Dimensions (W x H x D): 1628 × 1005 × 208mm
• Handle: YES
• VESA Standard Mount Interface: 600 x 400 mm

Environment Conditions:
• Operation Temperature: 0 °C to 40 °C
• Operation Humidity: 10 % to 90 %

Power:
• Power Supply: AC 100-240V~, 50/60Hz
• Power Type: Built-in Power

Power Consumption:
• Typ.: 220W
• Max.: 420W
• BTU (British Thermal Unit): 751 BTU/Hr(Typ.), 1433 BTU/Hr(Max.)
• DPM: 0.5W
• Power off: 0.5W

Sound:
• Speaker (Built-in): YES (15W x 2)
