LG 55VM5E 55 Inch 1920x1080 FUll HD 500nit 24/7 Narrow Bezel Commercial Display

Artistic Immersion, Overwhelming Captivation. The impressive immersion generated by the extremely narrow 0.9 mm bezel becomes even more powerful with a state-of-the-art smart signage platform. Beyond the self-playing feature, the VM5E series is capable of multitasking that raises brand awareness, drives traffic to your store, and engages customers in brand storytelling.

Narrow Bezels, verified by Nemko

• With its narrow 0.9 mm bezels and smaller seams, the VM5E series provides an immersive viewing experience on assembled video walls.

Image Gap Reduction

• The VM5E series includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a near seamless viewing experience.

Wide Viewing Angle

• LG IPS panels allow you to enjoy lifelike picture quality with minimal variation from wide viewing angles. Featuring excellent consistency in colour temperature and less change in contrast, LG IPS panels boast excellent image reproduction.

High-Performance SoC with webOS

• Quad Core SoC (System on Chip) can execute several tasks at the same time without a separate media player. Additionally, the webOS platform enhances user convenience with intuitive UI and simple app development tools.

Intuitive Menu Structure

• The menu structure has been optimised for commercial use. It simplifies the user experience and groups similar functions together, allowing for a more intuitive GUI.

Dedicated GUI for Portrait Orientation

• Whilst many displays have a GUI based on landscape-oriented TV usage, the GUI of the VM5E series is designed so that users can also install screens in a portrait orientation and maintain the user-friendly experience.

Easy Colour Adjustment

• Depending on the content, the colour temperature of the screen can be easily adjusted by users with a remote control.

Simple White Balance Adjustment

• In previous LG video walls, white balance was adjustable only in “full-white” mode, but the VM5E series allows you to modify each value of grey scale to achieve more detailed and precise white balance adjustment.

LAN Daisy Chain Support

• The LAN daisy chain feature allows users to control and monitor signage, distribute content, and even update firmware all at once.

Signage 365 Care

• Maintenance gets easier and faster with the optional Signage 365 Care service, an additional cloud service solution provided by LG*. Signage 365 Care remotely manages status of displays in your workspaces for fault diagnosis and remote services, helping ensure the stable operation of your business.

Panel:

• Screen Size: 55" (139cm)
• Panel Technology: IPS
• Aspect Ratio: 16:9
• Native Resolution: 1,920 x 1,080 (FHD)
• Brightness: 500 cd/m2
• Contrast Ratio: 1,200:1
• Dynamic CR: 30,000:1
• Viewing Angle (H x V): 178 × 178
• Colour Depth: 1.07 Billion
• Response Time: 8 ms (G to G)
• Surface Treatment: Haze 3%
• Life Time (Typ.): 60,000 Hrs
• Operation Hours: 24 Hrs
• Orientation: Landscape & Portrait

Connectivity:

• Input: HDMI (2), DP, DVI-D, Audio, USB 2.0
• Output DP, Audio
• External Control: RS232C In/out, RJ45 (LAN) In/out, IR In

Mechanical Specification:

• Bezel Colour: Black
• Bezel Width: 0.9 mm (Even), B to B) 1.8 mm)B to B: Panel bezel to panel bezel
• Monitor Dimension (W x H x D): 1,211.4 × 682.2 × 86.5 mm
• Weight (Head): 18.6 kg
• Carton Dimensions (W x H x D): 1,353 x 855 x 263 mm
• Packed Weight: 25.3 kg
• Handle: Yes
• VESATM Standard Mount Interface: 600 x 400 mm

Key Feature:

• Key Feature: Internal Memory 8GB (System 4GB + Available 4GB), Temperature Sensor, Tile Mode (Up to 15x15), Natural Mode @Tile Mode, ISM Method, DPM Select, Smart Energy Saving, Contents Scheduling (USB, Internal Memory), USB Cloning, Calibration Mode, Sync Mode, PM Mode, Firmware Update (LAN), HDMI-CEC 2), Wake on LAN, Fail Over, No Signal Image, Embedded Template, OPS Power Control, Scan Inversion (with Pivot Mode)
  2)Compatibility may differ by equipment.

Environment Conditions:

• Operation Temperature: 0 °C to 40 °C
• Operation Humidity: 10% to 80%

Power:

• Power Supply: 100-240V~, 50/60Hz
• Power Type: Built-In Power
• Power Consumption -Typ.: 160 W
• Power Consumption - Max: 180 W
• Power Consumption - Smart Energy Saving: 80 W

Certification:

• Safety: CB / NRTL
• EMC: AS/NZS CISPR32,RCM(Class A)
• ErP / Energy Star: Yes (EU Only) / Energy Star 8.0

Media Player Compatibility:

• OPS Type Compatible: Yes (Piggyback)

• Content Management Software: Super
• Sign CMSControl and Monitoring Software: Control/Control+

• Remote Controller
• Power Cord
• RS232C Cable
• LAN Cable
• DP Cable
• IR Receiver
• Guide Bracket
• Screws
• Manual
