Dell Pro Smart Dock SD25 130W USB-C Laptop Docking Station - 1x HDMI, 2x DisplayPort, 4x USB-A, 2x USB-C, 1x RJ45

Get the power and agility to work your way with the latest smart dock featuring up to 130W USB-C power delivery and remote management capabilities.

A smarter workspace:
Gain the versatility to create your ideal workspace and boost your AI PC productivity with support for up to 4 displays, up to 130W power delivery, and multiple ports to connect all your peripherals.

Remotely manageable:
Elevate the IT management experience with no software or PC connection required, allowing you to remotely manage all your Dell Pro Smart Docks.

Connect your way:
Configure your workspace to your liking with an ambidextrous USB-C cable that can be routed left or right.

Designed for sustainability:
The Dell Pro Smart Dock is built with post-consumer recycled materials and packaged with recycled or renewable packaging.

Technical Information:
• Connectivity Technology: Wired
• Number of Displays Supported: 4
• Device Supported: Notebook

Management Features:
• Host PC Management: MAC address pass-through, PXE Boot, Dock Power Button Sync, Wake-On-LAN, WLAN to LAN switch, Kernel Direct Memory Access (DMA) protection
• Dock Management Features: Remote firmware updates without a PC, Host PC based firmware updates, Firmware update on disconnect, Port Disablement independent of PC

Video Resolution: DP1.4 with Display Stream Compression:
• 4 x WQHD (3440 x 1440) @ 60Hz
• 3 x WQHD (3440 x 1440) @ 60Hz
• 2 x 5K (5120 x 2160) @ 60Hz
• 1 x 6K (6144 x 3456) @ 60Hz

Video Resolution: DP1.4 without Display Stream Compression: Up to:
• 4 x HD (1280x720) @ 60Hz
• 3 x FHD (1920x1080) @ 60Hz
• 2 x QHD (2560x1440) @ 60Hz
• 1 x 4K (3840 x 2160) @ 60Hz

Network & Communication:
• Ethernet Technology: RJ45 Ethernet port, 2.5GbE

Interfaces:
• Video interfaces: 2 x DP1.4, 1 x HDMI 2.1, 1 x USB-C 3.2 Gen 2 Multi-function DisplayPort 1.4
• USB Ports (Data Only): 4 x USB-A 3.2 Gen 2 (10 Gbps), 1 x USB-C 3.2 Gen 2 (10 Gbps)
• USB Ports (Power): 4 x USB-A 3.2 Gen 2 (4.5W each), 1 x USB-C 3.2 Gen 2 (15W), 1 x USB-C Multi-function DisplayPort (7.5W), All deliver power with or without PC
• USB Power Delivery: 130W (Dell systems), 96W (non-Dell systems)

Power Description:
• Maximum Power Supply Wattage: 180W

Physical Characteristics:
• Dimension (HxWxD): 205 x 90 x 35.25mm
• Weight (Approximate): 562 g

Operating System Supported:
• Windows 10
• Windows 11
• Ubuntu
• Red Hat Enterprise Linux
• ChromeOS
• macOS
