Product Description:
CUDY 10G Multi Mode Fibre LC SFP+ Module
SFP-100BASE-Tx Copper Small Form Pluggable (SFP) transceivers are based on the SFP Multi Source Agreement (MSA). They are compatible with the 10base-T / 100base-Tx standards as specified in IEEE Std 802.3. SFP-100BASE-T uses the SFP's RX_LOS pin for link indication. If pull up SFP's TX_DISABLE pin, SWITCH IC be reset.
Features:
• Support 10base-T / 100base-Tx
• Hot-pluggable SFP footprint
• Compact RJ-45 connector assembly
• RoHS compliant and lead-free
• Single +3.3V power supply
• 10/100base-Tx Fast Ethernet over Cat 5 cable
• Ambient Operating temperature: -40°C to +85°C
• Hot-pluggable SFP footprint
• Compact RJ-45 connector assembly
• RoHS compliant and lead-free
• Single +3.3V power supply
• 10/100base-Tx Fast Ethernet over Cat 5 cable
• Ambient Operating temperature: -40°C to +85°C
Specifications:
Cable Length:
• 10base-T CAT5: 200m
• 100base-Tx CAT5: 100m
+3.3 Volt Electrical Power Interface:
• Supply Current: 300 mA
• Input Voltage: 3.13 - 3.47 V
• Maximum Voltage: 4 V
Low-Speed Signals, Electronic Characteristics:
• SFP Output LOW: 0.5
• SFP Output HIGH: host_Vcc 0.5 - host_Vcc + 0.3 V
• SFP Input LOW: 0.8 V
• SFP Input HIGH: 2 - Vcc + 0.3 V
High-Speed Electrical Interface, Transmission Line-SFP:
• Line Frequency: 125 MHz
• Tx Output Impedance: 100 Ohm
• Rx Input Impedance: 100 Ohm
High-Speed Electrical Interface, Host-SFP:
• Single ended data input swing: 250 - 1200 mV
• Single ended data output swing: 350 - 800 mV
• Tx Input Impedance: 50 Ohm
• Rx Output Impedance: 50 Ohm
General:
• Data Rate: 10 - 100 Mb/sec
Environmental Specifications:
• Operating Temperature: -40 - 85 °C
• Storage Temperature: -40 - 85 °C
• 10base-T CAT5: 200m
• 100base-Tx CAT5: 100m
+3.3 Volt Electrical Power Interface:
• Supply Current: 300 mA
• Input Voltage: 3.13 - 3.47 V
• Maximum Voltage: 4 V
Low-Speed Signals, Electronic Characteristics:
• SFP Output LOW: 0.5
• SFP Output HIGH: host_Vcc 0.5 - host_Vcc + 0.3 V
• SFP Input LOW: 0.8 V
• SFP Input HIGH: 2 - Vcc + 0.3 V
High-Speed Electrical Interface, Transmission Line-SFP:
• Line Frequency: 125 MHz
• Tx Output Impedance: 100 Ohm
• Rx Input Impedance: 100 Ohm
High-Speed Electrical Interface, Host-SFP:
• Single ended data input swing: 250 - 1200 mV
• Single ended data output swing: 350 - 800 mV
• Tx Input Impedance: 50 Ohm
• Rx Output Impedance: 50 Ohm
General:
• Data Rate: 10 - 100 Mb/sec
Environmental Specifications:
• Operating Temperature: -40 - 85 °C
• Storage Temperature: -40 - 85 °C
Requirements:
• Generic Brand Compatibility
